BC2-10
LTE Cat1.bis
Slim Modem
Block Diagram
Key Features
Cellular Modem
LTE Cat 1.bis 3GPP Release 14, TDD/FDD FD
Up to DL 10 Mbps, UL 5 Mbps
RF
RF frequency range: 450 MHz to 2.7 GHz
Bandwidths: 1.4 / 3 / 5 / 10 / 15 / 20 MHz
Support up to 12 RX ports and 4 TX ports
Power Management
Low power consumption with PSM / eDRX modes
Interfaces
USB / I2C / SPI / UART / MIPI RFFE
Network Protocols
IPv4/IPv6/TCP/UDP/MQTT/CoAP/PPP/SNTP/SSL/TLS/
FTP/FTPS/HTTP/HTTPS/PING/LWM2M
Other Highlights
WiFi scan for positioning (indoor, city canyons)
FOTA
The Bridgecom BC2-10 is a LTE Cat1.bis IoT modem platform based on 3GPP R13, designed for the massive IoT market. Engineered for applications like smart metering, asset tracking, intelligent sensing, real-time device monitoring and predictive maintenance.
​
The BC2-106 slim modem chip delivers reliable LTE connectivity with lowest power, compact form factor, and minimal cost. Its high level of integration simplifies device design for seamless and smart IoT deployments—making it ready for scale.
LTE Cat1.bis
Slim Modem
Chipset
Part Number(s)
Memory Configuration
Ambient Operating Temperature
Product Status
4Mbit PSRAM + 4Mbit NOR Flash (SiP integration)
BC2-106 (with integrated BB, RF and PMU)
-40°C to 85°C
Qualified and in volume shipment
